Chapter 1 Basic Operation
VPanel Window and Functions
Top Window
The top window displays the statuses of connected milling machines and an output list of milling data. When
more than one machine is connected, the machine displayed in the MACHINE STATUS window is the target of the
operations.
No. Display Explanation
MATERIAL
This section displays the statuses of the adapters inserted in the adapter stocker.
Click
to read the IDs of the adapters installed in the adapter
stocker and to update the adapter statuses.
Adapter stocker number
Adapter ID
" P.31 "Adapter/Adapter ID"
Adapter status
Disk type present and planned to be used
Disk type present and not planned to be used
No disk type present
Unknown
Error
During milling
Milling complete and workpiece can be removed
