4.
Remove the detection pin and the automatic correction jig.
After removing the detection pin and the automatic correction jig, clean them, and then store them in the storage
compartment.
" P.61 "Care and Storage of Detection Pin and Automatic Correction Jig"
Detection pin
Procedure
Open the front cover and remove the detection pin.
Automatic correction jig
CAUTION
Do not pull the adapter with excessive force when removing it.
Doing so may result in injury arising from your hand or arm hitting something.
Procedure
Open the magazine cover, and then remove the automatic correction jig.
Hold the adapter with both hands and pull it out slowly. Exercise caution to prevent your hands or other
body parts from striking the inside of the magazine cover when you pull out the adapter.
Periodic Maintenance
70
Chapter 3 Maintenance
