Dieci APOLLO MINI AGRI - Transmission; Movement Selection Lever

8 | Components description
106 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
8.4 Transmission
8.4.1 Movement selection lever
CAUTION
In order to select a direction of movement, it is necessary to move the movement selection lever towards
the steering wheel. This shifting protects the lever from accidental operation.
With the movement selection lever in position other than "N", it is not possible to start the engine.
Themovementselectionlever,attheleftofthesteeringwheel
(fig.1504571),allowstosetthedirectionoftravelofthevehicle.
– Pullthelevertowardsthesteeringwheelandpushitforward
("F"direction)toproceedforward.
– Pullthelevertowardsthesteeringwheelandpullitback("R"
direction)toproceedinreverse.Whendrivinginreverse,an
alarmsoundsintermittently.
While holding the lever in an intermediate position ("N") the
transmissionisinneutralandthevehicleispartiallybraked.
With the forward/reverse movement gear selection lever in
positionotherthan"N",theenginewillnotstart.
150457-1
Afterselectingadirectionofmovement,thecorrespondingindicatorlightsontheinstrumentpanelturnon:
"F"forwardmovement
"R"reversemovement

Whileholdingtheleverintheintermediate"N"position
thetransmissionisinneutralandbothindicatorlights
willturnoff.
The movements of the lever are not active when:
– Thehandbrakeisengaged
– Theoperatorisnotproperlyseatedinthedriver'sseat
