7 | Vehicle description
64 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
7.2 Right side description
Illustration2: 1509881:Rightsideview
1 Enginehood 2 Telescopicboom
3 Boomhead 4 Toolsholderplate
5 Fuelfillercap 6 Epicycloidalreductiongear
7 Wheel 8 Rearaxle
9 Frontaxle 10 Rearhydraulicsockets(Optional)
11 Towhitch(Optional) 12 Rightrearheadlight
13 Rightfrontheadlight
