Dieci APOLLO MINI AGRI - Wiring Diagram; Components Legend

20 | Wiring diagram
236 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
20 Wiring diagram
20.1 Components legend
Name Description Sheet
A101 TOOL 1
A101 TOOL 2
A101 TOOL 3
A101 TOOL 4
A101 TOOL 4
A101 TOOL 5
A101 TOOL 8
A149 RIGHTLOUDSPEAKER 9
A151 RADIO 9
A159 RIGHTLOUDSPEAKER 9
A233 ACCELERATORPEDAL 6
A241 SARLCONTROLUNIT 6
A241 SARLCONTROLUNIT 3
A283 CANLINK 3
A744 ECUENGINESIDEKUBOTA 3
A744 ECUENGINESIDEKUBOTA 4
A745 ECUVEHICLESIDEKUBOTA 1
A745 ECUVEHICLESIDEKUBOTA 2
A745 ECUVEHICLESIDEKUBOTA 3
A745 ECUVEHICLESIDEKUBOTA 3
A745 ECUVEHICLESIDEKUBOTA 4
A745 ECUVEHICLESIDEKUBOTA 1
A747 ENGINEINTERMEDIATECONNECTOR 3
A747 ENGINEINTERMEDIATECONNECTOR 3
A747 ENGINEINTERMEDIATECONNECTOR 4
A748 INJECTORINTERMEDIATECONNECTOR 3
A749 DPFINTERMEDIATECONNECTOR 4
A754 DIAGNOSTICENGINEKUBOTA 3
B130 SEATMICROSWITCH 1
B139 STOPLIGHTSMICROSWITCH 8
B181 TRANSMISSIONDISCONNECTMICROSWITCH 2
B503 HORN 8
B512 DIESELLEVELSENSOR 4
B513 CLOGGEDHYDRAULICOILFILTERPRESSURESENSOR 4
B544 EXTENSIONSENSOR 7
B554 NEGATIVEBRAKEPRESSURESWITCH 2
B558 FRONTAXLEALIGNMENTPROXIMITYSWITCH 5
B559 AXLELOADCELL 6
B560 REARAXLEALIGNMENTPROXIMITYSWITCH 5
