Low/high beam light bulb replacement
– Removetheelectricalconnectorpullingittowardsyou.
– Liftthelockingtabs(fig.1503023)movingthemsidewaysto
releasethebulb.
– Afterreplacingthebulb,proceedinthereverseordertolock
and connect it again. Observe the joints of the lamp for
properinsertion.
150302-3
11.15.2 Tail light
Thetaillight(fig.1503041)iscomposedof:
Reversinglight21W
Rearsidelight5W
Brakinglight21W
Directionindicator21W
Rearfoglight21W
1
5
4
3
2
120304-1
Toaccessthebulbs:
1. Preparethevehicleinthemaintenanceposition.
2. Turnoffthebatterycutoffswitchtodisconnectpowertotheelectricalsystem.
3. Removethepowersupplyconnectoronthebackofthelight.
4. Removethefrontoftheheadlightbylooseningthescrewsplacedinthecap.
Toclosetheheadlightoperateinthereverseorder,payingattentiontocorrectpositioningofthegasket.
Tail light bulb replacement.
– Pressthetopofthebulb.
– Turnthebulb,keepingitpressed,toreleaseitfromthelock.
– Performthesameprocedureinreverseordertoinsertthenewbulb.
11.15.3 Work light *
NOTICE
* The work light is an optional accessory.
