8.2.2 Deactivating the parking brake manually
Theparkingbrakemustbedisengageddirectlyonthefrontaxle
withtheengineofftoallowthevehicletobetowed:
– Placesafetywedgesunderthewheelstopreventthevehicle
frommovingsuddenly.
– Unscrewthelowerprotectioncasing(ifpresent).
– Loosentheboltsonbothsides“A”and“B”(fig.1505601)of
thecentralbodyofthefrontaxleusinga24spanner.
– Loosen the bolts just enough to be able to slip off the “U
shaped"shims(fig.1505602and1505603).
– Tightenthepreviouslyloosenboltsallthewaydown.
Intheseconditionsitispossibletotowthevehicle.
A
B
150560-1
150560-2
150560-3
DANGER
Never use the vehicle with the negative parking brake disengaged/disconnected.
To return the brake to working condition, return in to its original conditions.
