9.7 Fork shifter
NOTICE
The Fork shifter is an optional equipment.
9.7.1 Fork shifter installation
Theequipmentinquestionallowstolaterallymovetheforksinstalledonit.
The data necessary for the identification are positioned on the
rightsideoftheequipment,intheupperpart“A”(fig.1505531).
A
150553-1
Belowaretheidentificationdata(theirordermaybedifferentontheforks).
1Model
………………………………….
4
5
6
7
2
3
1
150553-2
2Serialnumber
………………………………….
3Yearofmanufacture
………………………………….
4Mass(Kg)
………………………………….
5Capacity(Kg)
………………………………….
6  Maximum hydraulic pressure
(bar)
………………………………….
7Centerofgravity(mm)
………………………………….
Toensureapromptandefficientservice whenorderingpartsorwhenrequestinginformationortechnical
clarificationalwaysspecifytheidentificationdetails.
Thereforewerecommendtonotethedatarelatingtotheaccessoryinyourpossessioninordertosafelyand
quicklyidentifytheminthefuture,incaseofneed.
9.7.2 Fork shifter description
Theforkshifter(fig.1505541)consistofthefollowingmaincomponents:
