Dieci APOLLO MINI AGRI - Equipment Installation Procedure; Dieci Plate

9 | Equipment
144 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
9.2 Equipment installation procedure
9.2.1 Dieci Plate
To properly install equipment carry out the following operations
(fig.1505071):
1. Removethesafetypin"1"(ifinstalled)byremovingthesafety
pins"2"andliftingthelockingpins"3".
2. Placetheequipmentonaflatnotyieldingsurface,tobeableto
smoothlyengageitwiththetoolholderplateofthevehicle.
3. Place the vehicle with the boom lowered parallel to the tool.
Approachthetoolholderplatetotheaccessoryretractingthe
telescopicboom.Thevehiclecannotextendtheboomifitis
completely lowered. Slightly raise the boom to be able to
extendit.
4. Usingthetiltingmovement,rotate thetoolholder platedoor
downward.Bringthetopoftheplateunderthelockinghooks
ofthetool.
5. Slightlylifttheboomandrotatethetoolholderplateupwards,
thusmakingtheequipmentadheretothetoolholderplateof
thevehicle.Duringthisoperation,makesurethatnopersonis
inthevicinityoftheequipmentorthevehicleboom.
6. Turnofftheengineandgetoutofthevehicle.
7. Liftthelockpin“1”andinsertthesafetypins“3”intheirseats
ontoolholder plate,passingthroughthecorresponding slots
of the equipment. In the case the two holes do not match,
performthestepsdescribedinchapter"Safetypinoutline"
8. Fitthesafetypin“2”onthepinsjustinserted.
9. In the event that the equipment needs electrical orhydraulic
connections, refer to the "Hydraulic hoses connection" and
"Electricalcablesconnection"chapters.
10. Onceproperlyfixedtheequipment,turnonthevehicleandset
the correct mode of operation of the vehicle related to the
newlyinstalledequipment:
11. Consulttheuseandmaintenancemanualofthevehicletoset
thecorrectmodeofuse.
12. Checkthatinthecabthereisthecapacitydiagramrelatedto
thevehicleandtotheequipmentjustinstalled.
150507-1
1505072
