9.8 Bucket
9.8.1 Buckets identification
Bucketsallowhandlinginertmaterial.
Toensureapromptandefficientservicewhenorderingpartsor
when requesting information or technical clarification always
specifytheserialnumber.
Therefore we recommend to note the data relating to the
accessoryinyourpossessioninordertosafelyandquicklyidentify
theminthefuture,incaseofneed.
The data necessary for the identification of the buckets are
positionedontherightside,intheupperpart “A”(fig.1505221).
4
3
1
2
A
150522-1
9.8.2 Buckets description
All the buckets (fig.1505231) consist of the following
components:
1. Blade
2. Hooksforplateconnection
3. Tiltindicator
4. Hooksforlifting
4
3
1
2
A
150523-1
9.8.3 Buckets safety stickers
Safetystickersonthewinches(fig.1505241):
– AXA2427–Keepthesafetydistancefromtheequipment
AXA2427
150524-1
