Dieci APOLLO MINI AGRI - Hydraulic System Maintenance; Hydraulic Oil: Check and Replacement

Maintenance | 11
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 203
– Makesuretherearenoleaks,checkthelevelandaddmore
liquidifnecessary.
WARNING!The coolant level in the expansion tank "3",
refers only to the tank, it is not the total coolant level.
11.12 Hydraulic system maintenance
11.12.1 Hydraulic oil: Check and replacement
Thehydraulicoiltankislocatedattherear centerofthe frame,
underthetelescopicboom.
Thelevelcanbecheckedthroughthetransparentcapplacedon
theleftsideofthevehicle"1"(fig.1509081).
The level is correct when the oil is visible from the transparent
cap "1" with all the cylinders of the vehicle in the transport
position.
150980-1
NOTICE
See the chapter "Technical data" to know the amount and type of recommended oil.
Oil check
Tokeepthevehicleinnormaloperationconditions,itisnecessary
tokeeptheoillevelinbestconditions.
Toproperlychecktheoillevelinthetankitisnecessaryto:
– Preparethevehicleinthemaintenanceposition.
– Make sure that all cylinders and jacks of the vehicle are
retracted (e.g. telescopic boom fully retracted and lowered,
toolsholderplatetilteddownasmuchaspossibletoavoid
contact with chassis or tires). In this way all the oil of the
hydrauliccircuitwillbesentinthetank.
– Check the oil level through the transparent cap "1" (fig.
1509802). Under the best conditions, the oil level reaches
themiddleofthetransparentindicator.
– If necessary, remove the cap "1"(fig. 1509803) and add oil
untilitreachestheproperlevel.
150980-2
150980-3
Oil change
Tochangetheoilinthetankitisnecessaryto:
– Preparethevehicleinthemaintenanceposition.
– Make sure that all cylinders and jacks of the vehicle are
retracted (e.g. telescopic boom fully retracted and lowered,
toolsholderplatetilteddownasmuchaspossibletoavoid
contact with chassis or tires). In this way all the oil of the
hydrauliccircuitwillbesentinthetank.
