8 | Components description
130 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
8.18 Diagrams notebook
The diagrams notebook (fig. 1504621) summarizes the main
informationforsafeuseofthemachineforeasyreferencebythe
operatorduringthevariousprocessingphases.
150462-1
8.18.1 Capacity diagrams
TheSafeWorkingLoad(SWL)ofthesemachinesdependsontheextensionextentandtheboomangle.
Thecapacitydiagramsshowthe maximum height and extent allowed bycertainequipmentandloads,in
ordertoworksafely,withouttheriskoftippingofthemachineduringworkoperations.
Thismachineishoweverequippedwithanantitipdevicethatmonitorsinrealtimethestatusoftheloadand
theriskoftippingofthemachine(seechapter"warningdevice").Itishowevernecessarytouseandadhereto
thecapacitydiagramsinrelationtotheloadandtypeofaccessoryused.
CAUTION
It is mandatory to have in the cab, the capacity diagram referred to the equipment and
the machine that is being used.
Refer to the correct capacity diagram before handling a load.
DANGER
Danger of tipping.
Do not raise or extend the boom when the machine is in motion. Fully lower and retract the boom before
moving a load.
CAUTION
The capacity diagrams refer to stopped and leveled machine.
CAUTION
The diagrams of the machine and equipment being used must always be present in the
Diagram notebook found in the cab, used by the operator.
Replace the capacity diagrams if they deteriorate, are damaged or lost.
The capacity diagrams are ordered just like spare parts (make sure you provide the relative identification
code when placing the order).
Beforehandlingaloaditisnecessaryto:
– Consultthe"Safeworkingprocedures"chapter.
– Itismandatorytoknowtheweightoftheloadthatmustbehandled.
