8.1.5 Rear glass
Toopentherearglass,liftthehandle“1”(fig.1509041)andpush
theglassoutward.
Theglassismaintainedintheopenpositionbythehandle.
Toclosetherearglass,pullthehandlebackinthecabandlower
untilituntilthewholeunitiscompletelylocked.
150904-1
WARNING
Danger of crushing
In case the handle would no longer maintain the open position of the glass, replace it in the shortest
possible time.
NOTICE
The rear glass also serves as an emergency exit, see the "Safety Devices" chapter for more information.
8.1.6 Sunshade
TheSunshadeislocatedatthetopofthecab(fig.1509961).
TolowertheSunshade,takethehandlelocatedatthecenterof
"1"andloweritdowntolockitthehooksprovided"2".
Toclosethesunshade,lowerthehandle"1"toreleaseitfromthe
hooks"2"andtakebackthesunshadeinclosure.
150996-1
8.1.7 Cab ventilation
8.1.7.1 Ventilation adjustment
Toadjusttheventilationpresstheswitch“1”(fig.1509901).
Clicksindicaterespectively:
0Off
1–Firstspeed
2–Secondspeed
1
150990-1
