8.1.7.2 Air temperature adjustment
Toadjustthetemperatureofaircomingoutofthevents,move
thelever“1”locatedintherightsideoftheCab(fig.1509911):
– Move the lever forward (in the red scale) to increase the
temperature.
– Movetheleverbackward(inthebluescale)todecreasethe
temperatureuntilitisnexttotheoutsidetemperature.
150991-1
8.1.7.3 Air vents
Toopentheairventspressononesideoftheseandadjusttheair
flowdirectionusingthefinsorrotatingthevent.
Toclosetheventspushthefinsbringingthemtothehorizontal
closingposition.
150992-1
