Dieci APOLLO MINI AGRI - External Hydraulic Oil Intake Filter: Replacement; Brakes Maintenance; Brake: Inspection

Maintenance | 11
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 205
11.12.3 External hydraulic oil intake filter: Replacement
To replace the hydraulic oil filter carry out the following
operations:
– Preparethevehicleinthemaintenanceposition.
– Turnonthevehicleandlifttheboomjustenoughtoinsert
thesafetyrodontheliftingcylinderrod.
– Turnofftheengineandremovetheignitionkey,placeasign
inthecabshowing"Maintenanceinprogress".
– Insertthe"boomsupport"safetyrodontherodofthelifting
cylinder,applyappropriatesafetysupportstothetelescopic
boom.
– Allowengineandhydraulicoiltocooldown.
– Removethe safety clamp from the valve located inside the
chassis“1”(fig.1509821).
– Removetheenginelowerprotectionplate“1”(fig.1509822).
– Place a container under the oil filter "2" (fig. 1509822) to
collecttheoilthatmayspillduringthechange.
– Replacethefilter"2"(fig.1509822),lightlyoilthegasketand
tightenbyhandfor3/4ofaturn.
– Putbacktheenginelowerprotectionplate.
– Open the valve to position “1” (fig. 1509821) previously
closedandfastenwithanewclamp.
150982-1
150982-2
11.13 Brakes maintenance
11.13.1 Brake: Inspection
Visuallycheckthatthejointsofthepedals(fig.1507081)arenot
damagedandthatthepedalstrokeisnotexcessiveortooelastic.
150708-1
DANGER
If irregularities in braking are noticed, contact qualified personnel to verify the cause of
the trouble.
The braking parts also safeguard the operator's safety, it is recommended not to intervene personally on
the braking system trying to eliminate possible anomalies.
