11.19 Differential Axles Maintenance
11.19.1 Differential axles oil: Check and replacement
Thefiller,levelanddraincapsarelocatedinthecentralpartofthe
front(fig.1505801)andrear(fig.1505802)differentialaxle:
When checking the oil level it is necessary to:
– Preparethevehicleinthemaintenanceposition.
– Placeacontainerfortheoilrecoveryunderthelevelplug“1”
tocollectanyleaks.
– Openthelevelcap"1".Inthebestconditionsoilmustseep
outfromthehole.
– Ifnecessarytopuptomakeoilseepoutfromthelevelcap
“1”.
– Putbackthecapsandtightendown.
When replacing the oil it is necessary to:
– Preparethevehicleinthemaintenanceposition.
– Placeacontainerfortheoilrecoveryunderthedrainplug“2”
tocollectanyleaks.
– Openthelevelcap"1"andthenthedraincap"2".
– Drainoffalltheoil
– Closethedraincap"2".
– Loadnewoilfromthelevelcapof"1",uptomakeoilseep
out.
– Putbackthecapsandtightendown.
1
2
1505801
2
1
1505802
