8.13 Quick coupling
NOTICE
* The equipment quick coupling is an optional accessory.
Theequipmentquickcoupling allowsthe operatorto installandfastentheequipmenttothetoolsholder
plate.
Therearedifferentmodelsofquickcouplingsforequipment,theycanbewithasinglelockcylinderlockor
doublelockcylinder,theproceduresforusechangeaccordingtothetypeofhydraulicsystemofthevehicle.
To use the quick coupling (fig. 1502067) for the equipment
installationitisnecessaryto:
1. Carry out the normal hooking operations set out in
paragraphs 1, 2, 3 and 4 of the chapter "Equipment
installation".
2. PresstheQuickCouplingbutton"1"(fig.1502068)andatthe
sametimeoperatetherollerontheservicesjoysticktoopen
thequickcoupling.
3. Keepthequickcouplingopen,tilttheplateupwardtomake
sure that the equipment is fully resting on the tool holder
plate.
4. Release the roller on the services joystick and the Quick
couplingbutton“1”toclosethequickcouplingandlockthe
equipment.
5. If the equipment is not properly fastened, repeat the
installation.
150206-7
1
150206-8
DANGER
Do not operate without having properly secured the equipment to the plate, danger of load and
equipment falling.
