Dieci APOLLO MINI AGRI - Man Basket Recovery in Case of Failure

10 | Emergency procedure
182 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
10.2 Man basket recovery in case of failure
All vehicles with man basket or prearranged for its use, are equipped with a manual pump for operators
recoveryincaseofemergency(vehiclemalfunction).
Theoperationsallowedthroughtheemergencypumpare:
– retracttheboomextensions
– lowertheboom
WARNING
Two qualified and experienced operators, authorized by the security officer, are required to complete the
retraction operation.
To carry out the manual retraction of the boom, perform the
followingprocedure.
– Removethejoystick“1”unscrewingthefourfasteningscrews
“2”(fig.1507211)
– Recovertherodforthepumpactivationinthetoolbox
– Fastentherodtothepump“4”(fig.1507212)
150721-1
Retract the boom:
– Operator1(fig.1507212):
– Placethelever“5”inposition“A”
– Operatethehandpumpbymovingthelever
– Operator2(fig.1507213):
– Atthesametimeofthepumpoperationpullthelever
"6"tothelefttoretracttheboomextensions
To lower the boom:
– Operator1(fig.1507212):
– Placethelever“5”inposition“B”
– Operatethehandpumpbymovingthelever
– Operator2(fig.1507213):
– Atthesametimeofthepumpoperationpushthelever
"5"totherighttolowertheboom
1507212
1507213
