Dieci APOLLO MINI AGRI - Initial Check

Components description | 8
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 91
Position Indicator light Description
10 Red Flashing Brakesoillowlevel
Fixed Brakingsystemfailure
11 Green Fixed
12 Yellow Fixed Slowgearengaged*
13 Yellow Fixed Fastgearengaged*
14 Yellow Fixed Frontaxlewheelsalignment*
15 Yellow Fixed Rearaxlewheelsalignment*
16 Green Fixed Backwardmovementengaged
17    Notused
18 Blue Fixed Highbeam
19 Green Fixed Directionindicators
21 Green Fixed Sidelights
22  Red  Enginewaterhightemperature
23  Yellow  Fuelreserve
* Indicator lights used depending on configurations or optional equipment.
Position Indicator light Description
24 Yellow  Notused
25 Yellow  Notused
26 Yellow  Notused
27 Red  Notused
8.3.2 Initial check
Whenthepanelisswitchedon,thesystemwillperformacheck
ofalltheindicatorlightsandalltheindicators.Duringthecheck,
thescreenwillshowaloadingbar"1"(fig.1504261).
After completing the initial check the display shows the main
Homescreen.
1
150426-1
