Dieci APOLLO MINI AGRI - Internal Hydraulic Oil Intake Filter: Replacement

11 | Maintenance
204 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
– Place a container under the drain plug (located under the
tank).
– Removethefillercap"1"(fig.1509805)
– Remove the rear protective casing “3” (fig. 1509805)
removingthe4screwsatthecorners“2”(fig.1509805).
– Removethedrainplugtolettheoildrain"4"(fig.1509805).
– Putbackthedrainplug"4"(fig.1509805).
– Reassembletherearprotectivecasing"3"(fig.1509805).
– Fillthetankwiththeoilindicated
– Checkthelevelthroughtheindicator"1"(fig.1509804)after
starting the engine and operated all hydraulic controls to
removeairbubbles,ifany.
– Ifnecessary,topupthelevel.
150980-4
150980-5
11.12.2 Internal hydraulic oil intake filter: Replacement
The internal hydraulic oil intake filters are located inside the
hydraulicoiltank;toreplacethem,completelyemptythetank.It
isthereforeadvisabletocarryoutthereplacementoftheintake
filtersinconjunctionwiththeoilchange.
Toreplacetheintakefilter,carryoutthefollowingoperations:
– Preparethevehicleinthemaintenanceposition.
– Make sure that all cylinders and jacks of the vehicle are
retracted (e.g. telescopic boom fully retracted and lowered,
toolsholderplatetilteddownasmuchaspossibletoavoid
contact with chassis or tires). In this way all the oil of the
hydrauliccircuitwillbesentinthetank.
– Place a container under the drain plug (located under the
tank).
– Removethefillercap"1"(fig.1509811).
– Remove the rear protective casing “3” (fig. 1509812)
removingthe4screwsatthecorners“2”(fig.1509812).
– Removethedrainplugtolettheoildrain"4"(fig.1509812).
– Aftercompletelydrainingtheoil,removetheflange"1"(fig.
1509812)toaccesstotheintakefilters.
– Unscrew the intake filter located inside the tank with an
adjustablespanner.
– Installnewfiltersandtightenwithawrench.
– Removetheflange“1”(fig.1509812)
– Putbackthedrainplug"4"(fig.1509812).
– Reassembletherearprotectivecasing"3"(fig.1509812).
– Fillthetankwiththeoilindicated.
– Closethefillercap"1"(fig.1509812).
– Checkthelevelthroughtheindicator"1"(fig.1509811)after
starting the engine and operated all hydraulic controls to
removeairbubbles,ifany.
– Ifnecessary,topupthelevel.
150981-1
150981-2
