Dieci APOLLO MINI AGRI - Headlight

Maintenance | 11
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 211
11.15.1 Headlight
Thefrontlight(fig.1503011)iscomposedof:
1. Directionindicator21W
2. Frontsidelight4W
3. Lowbeamandhighbeamlight60/55WH4
1
3
2
1503011
To access the bulbs:
– Preparethevehicleinthemaintenanceposition.
– Turnoffthebatterycutoffswitchtodisconnectpowertotheelectricalsystem.
– Removethepowersupplyconnectoronthebackofthelight.
– Removethefrontoftheheadlightbylooseningthescrewsplacedintherearcap.
Toclosetheheadlightoperateinthereverseorder,payingattentiontocorrectpositioningofthegasket.
Direction indicator bulb replacement
– Pressthetopofthebulb(fig.1503021).
– Turnthebulb,keepingitpressed,toreleaseitfromthelock.
– Performthesameproceduretoinsertthenewbulb.
150302-1
Sidelight bulb replacement
– Grasp the rear part where the electrical connections are
placed(fig.1503022).
– Turnandpulltherearparttowardsyou.
– Extractthesupport,pressthetopofthebulb.
– Turnthebulb,keepingitpressed,toreleaseitfromthelock.
– Performthesameproceduretoinsertthenewbulb.Putback
thesupportinsideitsseat.
150302-2
