8 | Components description
94 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
General alarm icon Acoustic signal Condition
On Intermittent Generator,batteryfailure
On Intermittent Engineoillowpressure
On Intermittent Engineairfilterclogging
On Intermittent Hydrostaticoilfilterclogging
On Intermittent
Intermittent Continuous Reachedengineoverspeedlimit
Intermittent Continuous Reachedmaximumspeedlimit
8.3.6 Active errors
Thepresenceof errors will be reported by the general warning
icon,bytheacousticsignallasting1.5sec.andbythedisplaying
oftheerrorcodeontheHomescreeninsteadofthetime.
150432-1
Inthepresenceofmorethanoneerror,theerrorcodeswillbedisplayedcyclicallyevery2sec.ontheHome
screen.Attheendofthecycleshowingalltheactiveerrors,aniconwillbedisplayedthatindicatestheuserto
accesstheActiveErrorspagetoviewallactiveerrorsinthattime.
IncaseofanerrorfromtheSAR,theacousticsignalwillbecontinuousandtheerrorcodewillremainfixedon
theHomescreen.PresstheOKbuttontostopthesoundoftheacousticsignalandresumetheactiveerrors
displayingcycle.
ToentertheActiveerrorspageitisnecessaryto:
– PresstheMENUbutton,
– SelecttheActiveerrorsicon,
– PresstheOKbutton,
Use the UP and DOWN buttons to scroll though the pages if
there are several errors. The arrows at the bottom of page "1"
indicate the presence and directions in which the additional
pagesflow.
Press the MENU button at any time to return to the Home
screen.
150432-2
Eacherrorcodeisassociatedwithaniconthatidentifiesthenatureoftheerror:
Icon Example Description
01 000000000 Parkingbrakeserrorsorbrakesfailure
02 000 SARerrors
03 000000.00 Transmissionerrors
04 000000.00 Engineerrors
