9.5 Equipment removal
Tostorethe accessory,onceyou finishedusingit, carryoutthe
followingoperations:
1. Placethemachineonasolidandlevelground
2. Positiontheequipmentaboveasupportplatformtofacilitate
the handling and transportation of the single piece of
equipment.
3. Lowerandextendthevehicleboomofaboutonemeter.
4. Turnofftheengine.
5. Removethe electricalconnections,ifany(seethefollowing
chapter)
6. Remove the water connections, if any (see the following
chapter)
7. Release the equipment following the reverse procedure of
the equipment installation in accordance with the type of
plateinstalledonthevehicle.
8. Turnonthevehicleandswingdowninordertoreleasethe
toolholderplatefromtheequipment.
9. Once released the toolholder plate, retract the machine
boom.
1506041
NOTICE
The accessory placed on the ground must always be appropriately marked and barriers and clearances
must be laid on all sides of the area that it could occupy falling.
DANGER
After releasing the system pressure always wait for a minute before disconnecting the
couplings.
Always disconnect the hydraulic hoses of the tool before releasing it from the vehicle. Otherwise it is
possible to damage the pipes or cables and the tool may fall and be dragged.
9.5.1 Electrical connections removal
Toremovetheelectricalconnectionsfromtheequipment
itisnecessaryto:
1. Followsteps1,2,3and4oftheproceduretoremove
the equipment from the vehicle described in the
previouschapter.
2. Disconnect the plug of the equipment from the
boomloweringthetwosafetylevers(fig.1505141)
3. Position the plug of the equipment on its dummy
socket“1” (fig.1505142),fasteningitwiththesafety
levers“2”.
4. Disconnect the cover located on the boom dummy
socketandfititintheelectricalsocket(fig.1505143)
1
150514-1
