Dieci APOLLO MINI AGRI - Fork Extensions

9 | Equipment
164 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
– Depositaloadtotheground.
– Lowerandfullyretracttheboommovingtheforkstoabout1mabovetheground.
– Turnoffthevehicle.
– Getoffthevehicleandmanuallymovetheforkstothedesiredwidth.
9.6.6 Fork extensions
CAUTION
Before starting to use the equipment, inspect and test it as described in the section "Forks
Safe Working Procedures".
Before starting to use the equipment, refer to the "Safety regulations" and "Safe Working Procedures"
described in the manual of the machine on which the equipment is installed.
Theforkextensionsconsistsofthefollowing main components
(fig.1505211):
1. Extension
2. Fastenerpin
3. Safetyplug
1505211
Warnings for use
– Usetheextensionsonlywiththeforksforwhichtheywereconstructed.
– Beforeuse,checktheirintegrity.
– Alwaysapplythepinwiththerelatedsplitpin.
– Donotuseloadsexceedingthoseindicatedbytheforksonwhichtheforkextensionsaremounted.
– Refertothecapacitydiagramoftheforkstowhichareappliedtheextensionforks.
– Makesureoftheloadstability.
– Donottaketheloadwithasingleextension.
– Donotuseextensionsforpurposesotherthanthoseforwhichtheywereconstructed.
Installation
– Fittheextensionontheforksafterestablishingtheintegrityoftheextensionandtheforks.
– Putthefastenerpin“2”withtherelatedsafetypin“3”.
DANGER
Never use if the forks or the extensions if they are defective or show tampering signs.
Forks extension check
– Ateachusechecktheintegrityofweldsandrepairifnecessary.
