Wiring diagram | 20
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 237
Name Description Sheet
B585 SPEEDSENSOR 4
B638 CLOGGEDAIRFILTERSENSOR 4
B643 CLOSEDBOOMMICROSWITCH 6
B688 DIESELDECANTINGSENSOR 4
B746 AIRFLOWSENSOR 3
B762 30°BOOMMICROSWITCH 7
B763 15°BOOMMICROSWITCH 7
E102 RIGHTFRONTWORKLIGHT 9
E103 RIGHTREARWORKLIGHT 9
E104 LEFTFRONTWORKLIGHT 9
E118 LEFTREARWORKLIGHT 9
E127 ROTATINGLIGHT 9
E147 COURTESYLIGHT 9
E522 RIGHTREARHEADLIGHT 8
E524 PLATELIGHT 8
E526 LEFTFRONTLIGHT 8
E548 LEFTREARHEADLIGHT 8
E551 RIGHTFRONTLIGHT 8
F1 OUTRIGGERSCONSENTRELAYFUSE 5
F10 FUSE+15SERVICESLIGHTINGSWITCHES 2
F11 FRONTSIDELIGHTSFUSERIGHTANDREARLEFT 8
F12 LICENSEPLATELIGHTSANDHEADLIGHTSFUSE 8
F14 ANTITIPPINGSYSTEMFUSE 6
F15 FUSE+15RADIOCONTROLSWITCHANDROTATINGLAMP 1
F16 STOPLIGHTSMICROSWITCHFUSE 8
F17 BOOMLIGHTSSWITCHFUSE 9
F18 FUSENOTUSED 11
F19 FUSE+15BASKETKEY 1
F2 FUSE+30WARNING 8
F20 FUSENOTUSED 11
F21 WINCHRELAYFUSE 6
F22 WORKLIGHTSRELAYFUSE 9
F23 FUSE+30COLUMNSWITCHLIGHTSANDOVERHEADLIGHTSWITCH 8
F24 RIGHTREARWORKLIGHTFUSE 9
F25 FUSE+30ALGATOOL 4
F26 FUSENOTUSED 11
F27 REVERSEGEARLIGHTANDBUZZERFUSE 2
F28 LEVELLING+OUTRIGGERSSTABILIZATIONFUSE 7
F29 BOOMSUSPENSIONAUXPUMPFUSE 7
F3 LOWBEAMLIGHTSFUSE 8
F31 TRANSMISSIONDISCONNECTFUSE 2
F32 SUPPLYRELAYFUSEUDCIDANFOSS 7
F33 FANSPEEDFUSE 10
