20 | Wiring diagram
238 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
Name Description Sheet
F34 OPTIONALSUPPLIESFUSE 11
F35 FRONTELECTRICWINDOWMOTORFUSE 8
F36 FUSE+15REARELECTRICWINDOWRADIOANTENNA 9
F37 SUPPLY+15MC2MANDTOOLFUSE 4
F38 TRAILERANDSVANDSELECTORBUTTONFUSE 5
F39 SENSORS+WINCHFUSE 4
F4 POWERSOCKETFUSE 9
F40 RADIATORANDBOOMHEADSVFUSE 4
F41 ENGINESTOPFUSE 1
F42 SEATMICROSWITCHFUSE,SEATTEMP.STARTUPSAFETY 1
F43 INCHINGMICROSWITCHFUSE 1
F5 HIGHBEAMLIGHTSFUSE 8
F50 FUSEVPMC2M 6
F51 EVAPORATORFANFUSE 10
F540 CABMAIN+30FUSE 1
F541 STARTFUSE 1
F6 RIGHTFRONTWORKLIGHTFUSE 9
F7 LEFTFRONTWORKLIGHTFUSE 9
F750 KUBOTAMAINFUSE 1
F751 EGRVALVEFUSE 1
F752 ECU50STARTERFUSE 1
F755 CABMAIN+30FUSE 1
F8 HORNRELAYFUSE 8
FG1 ALTERNATORFUSE 1
FG2 PREHEATINGFUSE 1
G0 BATTERY 1
G529 ALTERNATOR 1
H296 KUBOTAENGINEMECH.PREHEATINGINDICATORLIGHT 1
H502 REVERSEGEARBUZZER 8
K1 STARTERANTIRESTARTCONTROLUNIT 1
K10 OUTRIGGERSCONSENTRELAY 5
K11 STARTUPFROMBASKETRELAY 1
K12 SERVICESCONSENTRELAY 1
K13 30°BOOMCONSENTRELAY 5
K14 EXTENSIONRELAYCONSENTRELAY 5
K15 NEUTRALGEARRELAY 2
K153 SERVICESRELAY 1
K16 TIMERCONTROLUNITRELAY 2
K17 ENGINESTOPRELAY 1
K18 RIGHTREARWORKLIGHTRELAY 9
K19 LEFTREARWORKLIGHTRELAY 9
K2 TIMERCONTROLUNIT 2
K20 WINCHRELAY 6
