Dieci APOLLO MINI AGRI - Page 239

Wiring diagram | 20
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 239
Name Description Sheet
K21 BASKETWARNINGLIGHTCONSENTRELAY 7
K22 30°BOOMCONSENTRELAY 7
K23 SUPPLYRELAYUDCIDANFOSS 7
K24 TRANSMISSIONDISCONNECTRELAY 2
K25 2ndPUMPANDDEADMANRELAY 7
K26 LOWBOOMRELAY 7
K27 30°BOOMRELAYCONSENTRELAY 7
K28 AUXPUMPSVRELAY 7
K29 REVERSINGLIGHTSANDREVERSINGBUZZERRELAY 2
K3 S.CUTOFF1SARL 7
K30 FORWARDSGEARRELAY 2
K302 NEGATIVENEUTRALSIGNALRELAY 2
K31 REVERSEGEARRELAY 2
K4 S.CUTOFF2SARL 7
K5 HORNRELAY 8
K530 STARTUPRELAY 1
K531 PREHEATINGRELAY 1
K6 LEFTFRONTWORKLIGHTRELAY 9
K7 RIGHTFRONTWORKLIGHTRELAY 9
K753 MAINRELAY 1
K8 HIGHBEAMLIGHTSRELAY 8
K9 LOWBEAMLIGHTSRELAY 8
M112 FRONTWINDOWWIPERMOTOR 8
M117 FRONTWINDOWWASHER 8
M119 REARWINDOWWASHER 8
M122 REARWINDOWWIPERMOTOR 9
M129 HEATINGMOTOR 10
M152 PNEUMATICSEAT 8
M520 STARTERMOTOR 1
M555 AIRCONDITIONEDCOMPRESSOR 10
M646 FUELPUMP 4
R1 PREHEATINGGLOWPLUGS 1
S0 BATTERYCUTOFFSWITCH 1
S106 REARWORKLIGHTSSWITCHES 9
S108 WARNINGSWITCH 8
S111 SVSWITCHBOOMHEAD 5
S115 ROTATINGLIGHTSWITCH 9
S121 PARKINGBRAKESWITCH 2
S131 REARSVSELECTOR 5
S132 TRAILERBUTTON 5
S136 WHEELSALIGNMENTSWITCH 5
S137 COLUMNSWITCH 2
S140 LIGHTSWITCH 8
