20 | Wiring diagram
240 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
Name Description Sheet
S141 STARTERPANEL 1
S146 KEYFOROPERATIONSRESTORING 6
S148 FRONTWORKLIGHTSSWITCH 9
S169 BOOMSUSPENSIONSWITCH 8
S197 FRONTWIPERSWITCH 9
S204 MUSHROOMHEADEMERGENCYPUSHBUTTON 1
S206 BOOMWORKLIGHTSWITCH 9
S295 INHIBIT/FORCEDREGENERATIONSWITCH 1
S303 QUICKCOUPLINGSWITCH 5
S332 REARWINDOWWASHERSWITCH 9
W177 ANTENNA 9
X154.p BASKETLINEINTERFACECONNECTOR 1
X165 POWERPOINT 9
X178.s OPTIONALPOWERSUPPLY 11
X283 CANBUSNODE 3
X284 CANBUSNODE 3
X285 CANBUSNODE 3
X286 CANBUSNODE 3
X300.p CHASSISLINEINTERFACECONNECTOR 5
X322.s DISTRIBUTORCONTROLUNITLINEINTERFACE 6
X323.s DISTRIBUTORCONTROLUNITLINEINTERFACE 6
X324.s DISTRIBUTORCONTROLUNITLINEINTERFACE 6
X324.s DISTRIBUTORCONTROLUNITLINEINTERFACE 3
X333.s AIRCONDITIONEDKIT 10
X587.p TRAILERSOCKETINTERFACE 8
Y523 PARKINGBRAKESOLENOIDVALVE 2
Y527 FORWARDGEARSOLENOIDVALVE 2
Y528 REVERSEGEARSOLENOIDVALVE 2
