AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 135
Positivejib
FixedFrontbasket
ExtensibleFrontbasket
FixedTrilateralbasket
ExtensibleTrilateralbasket
Trilateralbasket(X°=RightrotationY°=Leftrotation)
8.18.1.4 Operating modes legend for capacity diagrams
Maximumpressureappliedontheground
Prohibitionofoperatingwithunleveledmachine
Stabilizerslowered,0%extended
Stabilizerslowered,50%extended
Stabilizerslowered,100%extended
Prohibitedtoworkontires
Stabilizerslifted
