9 | Equipment
152 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
9.3.4.1 Push-Pull couplings connection when connected to a valve
ToconnectthePushPullquickcouplingstothevalveon
theboomhead:
1. Perform the equipment installation procedures
described in the chapter: "Equipment installation
procedure".
2. Turnoffthevehicle.
3. In case of closed center distributor, discharge the
system residue pressure (refer to chapter Closed
center distributor: Relieve the pressure through
the trailer Descent button [}154]).
4. Remove the protective cap from the equipment
hydraulicplugs(fig.1505111).
5. Removetheprotectivecapfromthehydraulicsockets
installed in the valve on the boom head (fig.
1505112).
6. Cleantheplugandsocket,ifsoiled
7. Pushtheringonthevalvesockettowardstheboom
(fig.1505113).
8. Placetheplugfullyinsidethesocketandreleasethe
ringofthevalve(fig.1505114).
9. Checkthehydraulictubeiscorrectlyfixed
10. Carryoutthesameoperationforbothhoses
150511-1
150511-2
150511-3
150511-4
NOTICE
Consult the equipment manual to verify correct operation.
