7. Carryoutthesameoperationforbothhoses
8. Checkthatthehydraulichosesarenottrappedinthe
toolholderplateorthattheycanbecrushedbythe
equipmentwhenitwillbeplacedonthefloor
9. Proceed with the subsequent operations to remove
theequipmentfromthevehicle
150513-2
9.5.2.1 Push-Pull couplings removal when connected to a valve
To disconnect the PushPull quick couplings from the
valveontheboomhead:
1. Followsteps1,2,3and4oftheproceduretoremove
the equipment from the vehicle described in the
previouschapter.
2. Ifaclosedcenterdistributorisinstalledonthevehicle,
perform the procedures described in the "Hydraulic
hosesconnections"chaptertoreleasepressureinthe
hydrauliccircuit.
3. Turnoffthevehicle.
4. Pushtheringofthesockettowardsthevehicleboom
“1”(fig.1505151).
5. Pulltheplugtowardsyourselftoremoveitfromthe
socket“2”.
6. Cleantheplugandsocket,ifsoiled
7. Fit the protective cap to the equipment hydraulic
plugs(fig.1505152).
8. Fittheprotectivecaptothehydraulicsocketsofthe
valve(fig.1505153).
9. Carryoutthesameoperationforbothtubes.
10. Checkthatthehydraulichosesarenottrappedinthe
toolholderplateorthattheycanbecrushedbythe
equipmentwhenitwillbeplacedonthefloor.
11. Proceed with the subsequent operations to remove
theequipmentfromthevehicle.
1
2
150515-1
1505152
1505153
