Components description | 8
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 75
8.1.12.1 Direction indicators
Movethelever(fig.1504021):
– Towardsyourselftoindicateacurvetotheright(R).
– Forwardtoindicateacurvetotheleft(L).
The indicators only work when the ignition switch is in the
positionofinstrumentationon.
The indicator light “1” on the central instrument panel will
activatethedirectionindicators.
1
150402-1
CAUTION
Push the multifunction lever in stand-by position after making the turn, return to the neutral position is
not automatic.
8.1.12.2 Horn
Press the button on the end of the lever "1"(fig.1504031), to
activatethehorn.
1
150403-1
8.1.12.3 Front window wiper
Presstheswitch“1”(fig.1504041)inintermediateposition“1”to
activate the front window wiper. To turn off the front window
wiperreturntheswitch“1”inposition“0”.
1
150404-1
WARNING
Worn blades cause viewing difficulties and scratches to the glass.
Replace the blades if they are damaged or worn.
