Digi XBee 3 ZigBee User Manual

AT commands Serial interfacing commands
Digi XBee® 3 Zigbee® RF Module
202
Bit field
Bit Description
0
0 = Native API output (0x90 frame type)
1 = Explicit API output (0x91 frame type)
1
0 = XBee handles Supported ZDO requests
1 = SupportedZDOrequest pass-through
2
0 = XBee handles UnsupportedZDOrequests(responds with ZDO not supported)
1 = Unsupported ZDOrequest pass-through
3
0 = XBee handles Binding requests(responds with ZDO not supported)
1 = Binding request pass-through
4
This bit is only applicable when AO bit 1 = 0 (XBee handles incoming ZDO)
1 = Echo supported ZDO requests to the serial port
5
1 = Prevent any ZDO messages from going out the serial port. This will also disable any pass-
through set by other AO bits.
Parameter range
0 - 0xFF
Default
0
AZ (Extended API Options)
Optionally output additional ZCL messages that would normally be masked by the XBee application.
Use this when debugging FOTA updates by enabling client-side messages to be sent out of the serial
port.
Parameter range
0x00 - 0x0A (bitfield)
Parameter Description
0 Suppress ZCL output
1 Output receive frames for FOTA update commands
2 Output supported ZCLpackets
3 Output Extended Modem Status (0x98) frames instead of Modem Status (0x8A) frames
when a Secure Session status change occurs
Default
0
