Digi XBee 3 ZigBee User Manual

Frame descriptions User Data Relay frame - 0x2D
Digi XBee® 3 Zigbee® RF Module
278
Example use cases
These examples show how to use this frame.
n You can use the frame to send data to an external processor through the XBee UART/SPI via
the BLE connection. Use a cellphone to send the frame with UART interface as a target. Data
contained within the frame is sent out the UART contained within an Output Frame. The
external processor then receives and acts on the frame.
n Use an external processor to output the frame over the UART with the BLE interface as a
target. This outputs the data contained in the frame as the Output Frame over the active BLE
connection via indication.
n An external processor outputs the Frame over the UART with the Micropython interface as a
target.
Example
This example frame could be used to send the message “Relay Data” to the MicroPython interface
using API mode 1 (AP = 1).
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x0D
Frame type 3 0x2D
Frame ID 4 0x01
Destination Interface 5 0x02
Data 6 0x52
7 0x65
8 0x6C
9 0x61
10 0x79
11 0x20
12 0x44
13 0x61
14 0x74
15 0x61
Checksum 16 0x38
