Frame descriptions AT Command Response frame - 0x88
Digi XBee® 3 Zigbee® RF Module
283
AT Command Response frame - 0x88
Description
A device sends this frame in response to an AT Command (0x08 or 0x09) frame. Some commands send
back multiple frames; for example, the ND command.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Framedata
fields Offset Description
Frame type 3 0x88
Frame ID 4
The FrameID used in the original AT Command request frame will be
populated in the corresponding response. If the FrameID in the AT Command
request was 0, then no response will be generated.
AT
command
5-6 Command name: two ASCIIcharacters that identify the command.
Command
status
7
0 = OK
1 = ERROR
2 = Invalid command
3 = Invalid parameter
4 = Tx failure
Command
data
The register data in binary format. If the host sets the register, the device
does not return this field.
Example
If you change the BD parameter on a local device with a frame ID of 0x01, and the parameter is valid,
the user receives the following response.
Frame data
fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x05
Frame type 3 0x88
Frame ID 4 0x01
