Digi XBee 3 ZigBee User Manual

Frame descriptions AT Command frame - 0x08
Digi XBee® 3 Zigbee® RF Module
255
AT Command frame - 0x08
Description
Use this frame to query or set command parameters on the local device. This API command applies
changes after running the command. You can query parameter values by sending the AT Command
frame - 0x08 with no parameter value field (the two-byte AT command is immediately followed by the
frame checksum). Any parameter that is set with this frame type will apply the change immediately. If
you wish to queue multiple parameter changes and apply them later, use the AT Command - Queue
Parameter Value frame - 0x09 instead.
When a command is queried, a AT Command Response frame - 0x88 is populated with the parameter
value that is currently set on the device.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Frame
data
fields Offset Description
Frame
type
3 0x08
Frame ID 4 Identifies the data frame for the host to correlate with a subsequent response
. If set to 0, the device does not send a response.
AT
command
5-6 Command name: two ASCII characters that identify the AT command.
Parameter
value
7-n If present, indicates the requested parameter value to set the given register.
If no characters are present, it queries the register.
Examples
The following example illustrates an AT Command frame where the device's NJ parameter value is
queried.
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x0
Frame type 3 0x08
Frame ID 4 0x52
