AT commands I/O settings commands

Digi XBee® 3 Zigbee® RF Module

216

Parameter Description

0 Disabled

SPI_CLKfor through-hole devices

N/A for surface-mount devices

2 ADC

3 Digital input

4 Digital output, low

5 Digital output, high

Default

D3 (DIO3/AD3/TH_SPI_SSEL Configuration)

Sets or displays the DIO3/AD3 configuration (Micro pin 28/SMT pin 30/TH pin 17).

Parameter range

SMT/MMT: 0, 2 - 5

TH: 0 - 5

Parameter Description

0 Disabled

SPI_SSEL for the through-hole device

N/A for surface-mount device

2 ADC

3 Digital input

4 Digital output, low

5 Digital output, high

Default

D4 (DIO4/TH_SPI_MOSI Configuration)

Sets or displays the DIO4 configuration (Micro pin 23/SMT pin 24/TH pin 11).

Parameter range

SMT/MMT: 0, 3 - 5

TH: 0, 1, 3 - 5

Default Chapter4
