Digi XBee 3 ZigBee User Manual

Frame descriptions Modem Status frame - 0x8A
Digi XBee® 3 Zigbee® RF Module
285
Modem Status frame - 0x8A
Description
Devices send the status messages in this frame in response to specific conditions.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Frame data
fields Offset Description
Frame type 3 0x8A
Status 4
0x00 = Hardware reset
0x01 = Watchdog timer reset
0x02 =Joined network (routers and end devices)
0x03 = Disassociated
0x06 = Coordinator started
0x07 = Network security key was updated
0x0D = Voltage supply limit exceeded
0x11 = Modem configuration changed while join in progress
0x3B = Secure session successfully established
0x3C = Secure session ended
0x3D = Secure session authentication failed
0x3E = Coordinator detected a PAN ID conflict but because CR = 0, no
action will be taken.
0x3F = Coordinator changed PAN ID due to a conflict
0x32 = BLE Connect
0x33 = BLE Disconnect
0x40 = Router PAN ID was changed by coordinator due to a conflict
0x42 = Network Watchdog timeout expired three times
0x80 = Stack error
Note The BLEConnect and BLE Disconnect events are reported over the UART/SPI interface in API
mode when a valid Bluetooth connection has been made and API mode has been unlocked, and also
when an unlocked connection disconnects.
Example
When a device powers up, it returns the following API frame.
Frame data fields Offset Example
Start delimiter 0 0x7E
