Digi XBee 3 ZigBee User Manual

AT commands I/O settings commands
Digi XBee® 3 Zigbee® RF Module
217
Parameter Description
0 Disabled
1
SPI_MOSI for the through-hole device
N/A for the surface-mount device
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D5 (DIO5/Associate Configuration)
Sets or displays the DIO5 configuration (Micro pin 26/SMT pin 28/TH pin 15).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
Associate LED indicator - blinks when associated
3 Digital input
4 Digital output, default low
5 Digital output, default high
Default
1
D8 (DIO8/DTR/SLP_RQ)
Sets or displays the DIO8/DTR/SLP_RQ configuration (Micro pin 9/SMT pin 10/TH pin 9).
Parameter range
0, 1, 3 - 5
Parameter Description
0 Disabled
1
DTR/Sleep Request (used with pin hibernate and cyclic sleep with pin wake)
3 Digital input
