AT commands I/O settings commands
Digi XBe 3 Zigbe RF Module
219
P1 (DIO11 Configuration)
Sets or displays the DIO11 configuration (Micro pin 8/SMT pin 8/TH pin 7).
Parameter range
0, 2 - 5
Parameter Description
0 Disabled
1 N/A
2
PWM1 output. M1 (PWM1 Duty Cycle) controls the value.
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
P2 (DIO12/TH_SPI_MISO Configuration)
Sets or displays the DIO12 configuration (Micro pin 5/SMT pin 5/TH pin 4).
Parameter range
SMT/MMT: 0, 3 - 5
TH: 0, 1, 3 - 5
Parameter Description
0 Disabled
1
SPI_MISO for the through-hole device
N/A for the surface-mount and micro device
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
P5 (DIO15/SPI_MISO Configuration)
Sets or displays the DIO15 configuration (Micro pin 16/SMT pin 17/TH Pin N/A).
Note The DIO15 configuration is not available with the XBee 3 through-hole module.
