AT commands I/O settings commands
Digi XBe 3 Zigbe RF Module
222
Default
0
PR (Pull-up/Down Resistor Enable)
The bit field that configures the internal pull-up resistor status for the I/O lines.
n If you set a PR bit to 1, it enables the pull-up/down resistor
n If you set a PR bit to 0, it specifies no internal pull-up/down resistor.
PR and PD only affect lines that are configured as digital inputs (3) or disabled (0).
The following table defines the bit-field map for PR and PD commands.
Bit I/O line Micro pin Surface-mount pin Through-hole pin
0 DIO4 23 24 11
1 DIO3 28 30 17
2 DIO2 29 31 18
3 DIO1 30 32 19
4 DIO0 31 33 20
5 DIO6 27 29 16
6 DIO8 9 10 9
7 DIO14 4 4 3
8 DIO5 26 28 15
9 DIO9 25 26 13
10 DIO12 5 5 4
11 DIO10 7 7 6
12 DIO11 8 8 7
13 DIO7 24 25 12
14 DIO13 3 3 2
15 DIO15 16 17 N/A
16 DIO16 15 16 N/A
17 DIO17 14 15 N/A
18 DIO18 13 14 N/A
19 DIO19 11 12 N/A
Parameter range
Through-hole: 0 - 0xFFFF
SMT/MMT: 0 - 0xFFFFF
