Frame descriptions Register Device Status - 0xA4
Digi XBee® 3 Zigbee® RF Module
313
Device C 16-bit address: 0xCCDD
Device B 16-bit address: 0xAABB
The concentrator emits the following frame out of the serial port:
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x13
Frame type 3 0xA1
64-bit source (remote) address MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x40
10 0x11
11 0x22
Source (updater) 16-bit address 12 0x33
13 0x44
Receive options 14 0x01
Number of Addresses 15 0x03
Address 1 16 0xEE
17 0xFF
Address 2 (closer hop) 18 0xCC
19 0xDD
Address n (neighbor of source) 20 0xAA
21 0xBB
Checksum 22 0x80
Register Device Status - 0xA4
Description
This frame is sent out of the UART of the trust center as a response to a 0x24 Register Device frame,
indicating whether the registration was successful or not.
