Frame descriptions Many-to-One Route Request Indicator - 0xA3
Digi XBee® 3 Zigbee® RF Module
315
Many-to-One Route Request Indicator - 0xA3
Description
A many-to-one route request is sent as a broadcast message from a concentrator (AR < 0xFF).
When a node receives a many-to-one broadcast, it will create a route table entry for the concentrator,
preventing the need to do a route discovery when sending data to that destination.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Frame data
fields Offset Description
Frame type 3 0xA3
64-bit source
(remote)
address
4-11 MSB first, LSB last. The 64-bit address of the device that sent the many-to-
one route request.
Source
16-bit address
12-13 MSB first, LSB last. The 16-bit address of the device that initiated the
many-to-one route request.
Reserved 14
Set to 0.
Example
Suppose a device with a 64-bit address of 0x0013A200 40401122 and 16-bit address of 0x0000 sends a
many-to-one route request. All remote routers operating in API mode that receive the many-to-one
broadcast send the following example API frame out their serial port.
Frame data fields Offset Example
Start delimiter 0 0x7E
Length MSB 1 0x00
LSB 2 0x0C
Frame type 3 0xA3
