Digi XBee 3 ZigBee - P6 (DIO16;SPI_MOSI Configuration); P7 (DIO17;SPI_SSEL Configuration)

AT commands I/O settings commands
Digi XBee® 3 Zigbee® RF Module
220
Parameter range
0, 4, 5
Parameter Description
0 Disabled
1
SPI_MISO
4 Digital output, low
5 Digital output, high
Default
0
P6 (DIO16/SPI_MOSI Configuration)
Sets or displays the DIO16 configuration (Micro pin 15/SMT pin 16/TH Pin N/A).
Note The DIO16 configuration is not available with the XBee 3 through-hole module.
Parameter range
0, 4, 5
Parameter Description
0 Disabled
1 SPI_MOSI
4 Digital output, low
5 Digital output, high
Default
0
P7 (DIO17/SPI_SSEL Configuration)
Sets or displays the DIO17 configuration (Micro pin 14/SMT pin 15/TH Pin N/A).
Note The DIO17 configuration is not available with the XBee 3 through-hole module.
Parameter range
0, 4, 5
Parameter Description
0 Disabled
