Digi XBee 3 ZigBee User Manual

Frame descriptions Create Source Route - 0x21
Digi XBee® 3 Zigbee® RF Module
269
Frame
data
fields Offset Description
Address 2
(closer
hop)
19 Address of intermediate hop
20
Address 3 21 Neighbor of source
22
Example
You must order intermediate hop addresses starting with the neighbor of the destination and working
closer to the source.
Suppose a route is found between A and E as shown in the following example.
A ' B ' C ' D ' E
If device E has the 64-bit and 16-bit addresses of 0x0013A200 40401122 and 0x3344, and if devices B,
C, and D have the following 16-bit addresses:
B = 0xAABB C = 0xCCDD D = 0xEEFF
This example shows how to send the Create Source Route frame to establish a source route between
A and E.
Frame data fields Offset Example
Start delimiter 0 0x7E
Length
MSB 1 0x00
LSB 2 0x14
Frame type
3 0x21
Frame ID
4 0x00
64-bit destination address
MSB 5 0x00
6 0x13
7 0xA2
8 0x00
9 0x40
10 0x40
11 0x11
LSB 12 0x22
16-bit destination
network address
MSB 13
0x33
LSB 14
0x44
