Frame descriptions TX Status frame - 0x89

Digi XBee® 3 Zigbee® RF Module

289

Frame data fields Offset Description

Frame type 3 0x89

Frame ID 4

Identifies the TX Request frame being reported.

If the Frame ID = 0 in the TX Request, no TX Status frame is given.

Status

0x7C = Invalid Relay Frame Interface

0x7D = Relay Interface not accepting frames

Notes:

n The TX Status frame - 0x89 only occurs in response to a failure of the User Data Relay frame -

0x2D.

n See User Data Relay frame - 0x2D for more information.

Example

The following example shows a successful status received.

Frame data fields Offset Example

Start delimiter 0 0x7E

Length MSB 1 0x00

LSB 2 0x03

Frame type 3 0x89

Frame ID 4 0x01

Status 5 0x7D

Checksum 6 0xF8
