Frame descriptions Receive Packet frame - 0x90

Digi XBee® 3 Zigbee® RF Module

291

Frame data fields Offset Example

Length MSB 1 0x00

LSB 2 0x12

Frame type

3 0x90

64-bit source address MSB 4 0x00

5 0x13

6 0xA2

7 0x00

8 0x40

9 0x52

10 0x2B

LSB 11 0xAA

16-bit source network address

MSB 12

0x7D

LSB 13

0x84

Receive options 14 (Acknowledged)

Received data 15 0x52

16 0x78

17 0x44

18 0x61

19 0x74

20 0x61

Checksum 21 0x0D
