OperationModel 2500 71
© 2015-2017 Distek, Inc. All Rights Reserved
For Paddles
1 With the drive head fully raised, position the Quick Height Adjustment block to PADDLES
(USP 2).
Height adjustment block position for paddles
2 Install and secure (finger tight) the paddle blades.
3 Lower the drive head and turn the knob to lock position. The distance of 25±2 mm
between the blade and the inside bottom of the vessel is set and maintained during the
test.
