Sweep Frequency Response Analyzer (SFRA) User Guide
E-2 72A-2570-01 Rev. K 07/2011
Sampling Simultaneous
Frequency Range 10 Hz to 25 MHz
Max. Sampling rate 100 MS/s
Input Impedance 50 ohms
Calibration Interval 3 years
Data Collection
Test Method Sweep frequency
PC Communication USB/Ethernet
Frequency Range 10 Hz to 25 MHz
Number of Points 1000 (default); up to 1800 (extended range)
Point Spacing 1.2% logarithmic
Dynamic Range >90 dB
Repeatability ±1 dB to –80 dB
IF Bandwidth < 10% of active frequency
Data Display
Scaling Linear/Log
Frequency Range 10 Hz to 25 MHz, user-defined within frequency
range
Plotting Frequency vs. magnitude / phase
Analysis Difference, Sub-band cross-correlation
Physical Specifications
Dimensions M5200: 10.0 H x 16.0 W x 15.5 D in.
(25 H x 41 W x 40 D cm)
M5300: 10.0 H x 16.0 W x 15.5 D in.
(25 H x 41 W x 40 D cm)
M5400: 18.2 H x 13.4 W x 6.7 D in.
(46.2 H x 34.0 W x 17.0 D cm)
Table E.1 Instrument Specifications (Continued)
Feature Definition
