Sweep Frequency Response Analyzer (SFRA) User Guide
3-8
72A-25
70-01 Rev
. K 07/201
1
Run the Shorted-lead T
est
T
o run the shorted-lead test:
1.
In the main SFRA window
,
click
Select App
aratus
.
The Apparatus Selection window appears (
Figure
3.1
1
).
Figure 3.1
1 Appara
tus Selection W
indow
2.
Select
Leads
in the Manufacturer column and click
OK
.
3.
Click
St
art T
e
st
(
Figure
3.12
)
.
Figure 3.12 Locati
on of S
tart T
est Button
31
